Before & After Photos

This photo set taken from a basement shows the transformation of a bowing wall repair project in Frankfort, KY. The before photo highlights the shearing symptom, which happens in late stage of wall failure, and is super dangerous. Shearing occurs when there is so much external pressure that the wall slowly starts to slide inwards, right over the floor slab. This wall was at a very high risk for complete structural failure. After we repaired the wall with a bracing system, we were able to push the wall back to a plum position. In fact, our crew was able to push the wall back 3 inches far. This repair process was very delicate, but our crew was able to handle the pressure. If you wish to read more about this project, we have a case study that you can read by clicking here.

This home's front side wall in Harrodsburg, KY, was moving inwards towards the basement floor. Because the backside of the home features a walkout basement, there wasn't enough opposing soil pressure on that side to suggest a traditional wall bracing system. Without the counterforce, bracing the front side wall could cause damage to the floor joists and even cause the backside of the home to kick outwards near the top of the wall. Because of this situation, we suggested repairing the wall by installing our helical tieback system and our wall anchors. We were able to drill our helical rods horizontally through the front side wall into the soil beneath the lawn in the front yard. After pulling the wall back, we then tarred the wall around the rods to seal the wall, safeguarding it from leaking. Lastly, we anchored the wall with our wall plates to help secure the rods. You may also notice that we waterproofed this basement as well by wrapping the perimeter with our WaterGuard subfloor drains, wrapping the walls with our white CleanSpace vapor barrier, and installing a sump pump (not pictured).

This Sadieville, KY, homeowner had a collapsing retaining wall near their driveway that had started to lean outward from years of soil pressure. The movement was beginning to affect the stability of the driveway and raised concerns about long-term safety. Our crew installed two helical tiebacks and two wall anchors to pull the wall back toward its original position and lock it securely in place. What was once a visibly leaning wall is now straight, stable, and ready to hold strong for years to come.

This below grade garage was receiving a lot of hydro-static pressure around certain walls. When this happens, the walls tend to bow in and cracks begin to form from the large amount of water that is sitting around the foundation. We first relieved the pressure by drilling weeping holes into the trenches where the waterproofing system will go. WaterGuard was then placed into the trenches, connected to a TripleSafe sump pump and a discharge line. We then placed CleanSpace walls and PowerBraces to hold the bowing walls up. The CleanSpace walls function as a funnel for moisture seeping through the walls and the CleanSpace also looks cosmetically pleasing as well.

When we gave a free inspection for this basement in Irvine, Kentucky, we noticed a main beam needed a little extra support holding up the floor joists above it, so we recommended we install a SmartJack post. This post is covered in galvanized steel to prevent rusting. Not only were we able to waterproof this basement, but we were able to straighten out their floors as well!
