Before & After Photos

The soil under this Stanton, KY, home was settling, causing a gap to appear between the bottom of their brick wall and the block foundation. We were able to raise the foundation by utilizing helical piers, which effectively transferred the weight of the home to load-bearing soil. We were then able to raise the foundation with hydraulics, which helped close the gap.

In this Bagdad, KY, crawl space, the block foundation wall had shifted inward, leaving visible cracks and gaps along the mortar lines. From the inside, you can clearly see where the wall had moved out of position, creating uneven lines and open joints between blocks To correct the issue, our crew installed 4 helical wall anchors. Each anchor is drilled through the foundation wall and extended deep into stable soil outside of the home. On the inside, 7-inch wide steel plates are attached to the wall where the anchor rod passes through. Once everything is in place, the anchor rod is tightened, pulling against the soil outside and the plate inside. This creates a counterforce strong enough to gradually pull the wall back toward its original position. In the after photo, you can see the results: The gaps between the blocks have closed up significantly, and the wall is visibly straighter. Our wall anchor system provides immediate correction and long-term stabilization, giving homeowners peace of mind that the foundation is secure.

This homeowner wanted an egress window installed in their finished basement so that they could claim a bedroom on their homes appraisal. We started by digging a trench and cutting the concrete to make room for the 35x54 inch window and the RockWell window well. The well mimics a natural stone, and is made of a high-strength fiberglass composite. The well contains stair steps, allowing for easy access. The window well cover is translucent and allows for natural sunlight to fill the basement. We also made sure to caulk all the seams correctly. The homeowner was very happy with the outcome.

The owner of this home had a sinking crawl space that was resulting in sagging floors. In the "before" picture you can see their old jacks were not adjustable, meaning they could not change the height of the jacks to adjust for the sinking crawl space. Their old jacks were also rusting and becoming weaker. Luckily, our SmartJacks are able to be adjusted throughout time, countering the sinking crawl space effect. They are also a lot stronger and durable than the old ones, and will not rust.

This poured foundation in Owenton, KY, was failing due to built up hydrostatic pressure. This pressure had caused the wall to move, and eventually crack. The crack would leak from time to time, and it was seemingly growing larger by the season. We ended up repairing the wall by securing it with a helical tieback system. By drilling rods laterally through the wall into the soil beyond the basement, and then securing the wall with anchor plates, we were able to stabilize the wall, preventing it from moving any further. This process then allowed us to seal the leaky crack with our FlexiSpan system. Our FlexiSpan system drains the leak down underneath the floor slab by the use of gravity. This sealing and wall repair system will keep this wall dry and secure.
